Description
- Black Aluminum 3” voice coil former for superior heat dissipation
- High Temperature Round-Wire ALU voice coil with high-temp black adhesive
- Double stitched surround
- Heavy duty cast baskets – all new, custom-tooled
- Spring loaded terminals accept up to 8 gauge
- Stitched-on double-XL tinsel leads
- Solid pole with vent channels and aluminum shorting ring cap
- Rear drilled gap-venting
- Innovative high-velocity cast aluminum vented frame spacer ring
- Magnet ID shorting ring
- Top-Plate Cooling Channels
- Cast Aluminum surround bolt-on rings
- Optimized for small ported or bandpass enclosures
U-15
Sealed Enclosure
2.0 cu ft
Ported Enclosure
3.0 cu ft
Recommended Tuning
35Hz
Recommended Port Area
48 sq in
Displacement
0.24 cu ft
Depth
9.05″
Outside Diameter
15.59″
Cut-Out
14.01″
