Description
U-12v2 1750 watts
- Black Aluminum 3” voice coil former for superior heat dissipation
- High Temperature Round-Wire ALU voice coil with high-temp black adhesive
- Double stitched surround
- Heavy duty cast baskets – all new, custom-tooled
- Spring loaded terminals accept up to 8 gauge
- Stitched-on double-XL tinsel leads
- Solid pole with vent channels and aluminum shorting ring cap
- Rear drilled gap-venting
- Innovative high-velocity cast aluminum vented frame spacer ring
- Magnet ID shorting ring
- Top-Plate Cooling Channels
- Cast Aluminum surround bolt-on rings
- Optimized for small ported or bandpass enclosures
| Sealed Enclosure | 1.0 cu ft |
| Ported Enclosure | 2.0 cu ft |
| Recommended Tuning | 35Hz |
| Recommended Port Area | 32 sq in |
| Displacement | 0.21 cu ft |
| Depth | 7.75″ |
| Outside Diameter | 12.83″ |
| Cut-Out | 11.01″ |
