| SALT-6 DIGITAL MONOBLOCK FEATURES |
| • Digital Class-D Linkable Mono Block Amplifier |
| • Dual MOS-FET PWM Power Supply |
| • 1 Ohm Stable Load |
| • 24 dB/Octave – Variable Low Pass Filter |
| • 24 dB/Octave – Variable Subsonic Filter |
| • 9 dB/Octave – Variable Bass Boost |
| • 180° Variable Phase Shift |
| • 4 Way Protection Ciruit (Thermal, Voltage, Speaker Short, DC Offset) |
| • Wired Remote Control with Voltage & Temperature Display and Clipping Indicator |
| SPECIFICATIONS (Tested @ 14.4v) | |
| 2 ohm Linked RMS | 12000W |
| 1 ohm Mono RMS | 6000W |
| 2 ohm Mono RMS | 3000W |
| 4 ohm Mono RMS | 1500W |
| Recommended Fuse Rating | 600A |
| Low Pass Filter (Variable) | 35Hz-250Hz |
| Subsonic Filter (Variable) | 10Hz-50Hz |
| Bass Boost @ 45Hz | 0-9dB |
| Phase Shift Control | 0-180 Degrees |
| Input Sensitivity (+/- 5%) | 6v-0.2v |
| Frequency Response (+/- 1dB) | 10Hz-250Hz |
| S/N Ratio | 90dB |
| Working Voltage | 9v-15.5v |
| T.H.D @ 4ohms | < 0.1% |
| Efficiency @ 4ohms | 90% < |
| Dimensions | 26.78″ x 10.08″ x 2.96″ |
