Description
The M-series is really a different kind of woofer due to its incredibly linear suspension. They are designed for the LOWEST level of bass extension possible in a small enclosure while maintaining extremely low levels of distortion. This is all thanks to the Sundown Mega-Roll surround & proprietary Sundown PG linear suspension (fully computer optimized). As with most subwoofers from Sundown the M-series features a magnet inner-diameter aluminum shorting ring for superior inductive distortion performance as well.
- 2000 Watts RMS / 4000 Watts Peak
- Mega Roll Surround and Frame
- Etched All Black Backplate
- Quad Stack Magnet Structure
Specifications
| RE (Ohms) | 2.22 | 4.0669 |
| FS (Hz) | 31.931 | 32.714 |
| VAS (L) | 39.313 | 15.06 |
| Qes | 0.696 | 0.686 |
| Qms | 4.654 | 4.768 |
| Qts | 0.606 | 0.6 |
| Le (mH) | 1.946 | 3.641 |
| BL (NA) | 17.484 | 23.84 |
| Mms (Grams) | 477.932 | 466.6312 |
| Cms (uM/N) | 51.979 | 50.725 |
| Sens (dB @ 1w/1m) | 84.387 | 80.6 |
| Xmax | 35mm | 35mm |
| T/S SPECS | M12D1 | M12D2 |
|---|
Enclosure Specifications
| Sealed Enclosure | Not Recommended |
| Ported Enclosure | 2.5 cu ft |
| Recommended Tuning | 32Hz |
| Recommended Port Area | 40 sq in |
| 4th Order Sealed Side | 1.0 cu ft |
| 4th Order Ported Side | 3.0 cu ft |
| 4th Order Port Area | 60 sq in |
| 4th Order Port Length | 8″ |
| Displacement | 0.21 cu ft |
| Depth | 10.88″ |
| Outside Diameter | 12.67″ |
| Cut-Out | 11.09″ |
