Description

To fully harness the power of this beast, an electrical upgrade is mandatory. Failing to upgrade your electrical system will void the warranty. Required upgrades include:

• The Big 3
• Upgraded Alternator
• Reserve Battery(s)

Power Ratings (Tested at 14.4V @ 1% THD)

• 1-ohm: 3300W RMS
• 2-ohm: 2300W RMS
• 4-ohm: 1200W RMS

Additional Specifications

• Frequency Response: 14Hz – 260Hz
• Signal-to-Noise Ratio: 96dB
• Damping Factor: < 300
• Input Sensitivity: 6V – 0.2V
• Subsonic Filter: 10Hz – 50Hz
• Low Pass Filter: 35Hz – 250Hz
• Phase Control: 0 – 180 degrees
• Strappable Connection: Yes
• Speaker Connection: Operable down to half an ohm
• Fusing: 350A Total (175A for each positive input)
• Clipping Indicator: Yes
• BT Remote Control: Includes voltage and temperature display, and clipping indicator
• Power Connection for BT Remote: C-type (external battery pack or USB power required; unit does not have rechargeable batteries)
• Speaker Output: 4-gauge
• Power Inputs: 2 x 0-gauge
• Operating Voltage: 9 to 16 Volts
• Dimensions: 13.8″ (L) x 9.37″ (W) x 2.63″ (H)
• Country of Origin: Made in South Korea
