Description

Features:

1. Field-Replaceable Recone Kit – cone/voice coil/spider assembly, and no gluing required
2. Forced Air Cooling™
3. Three-inch, aluminum voice coil former
4. Dual-spider suspension
5. Double-pressed pulp cone
6. Heavy-duty UV-resistant Santoprene surround
7. Custom rubber magnet boot
8. Cast-aluminum basket
9. Single 8 AWG terminal and dual 8 AWG terminal block
10. Triple-Stacked Ferrite Magnet
11. Specifications

    Thiele/Small Parameters

    49L7X152 T/S Parameters

    Size (in, cm)

    15, 38

    Rated Impedance (Ohms)

    2 DVC

    Rec Amp Power rms

    1000-2000

    Frequency Response

    20-100

    Magnet Diameter (in, cm)

    8-11/16, 22

    Total Magnet Weight (oz, kg)

    406, 11.5

    Voice Coil Diameter (in, mm)

    3, 75

    Voice Coil Winding Width (in, mm)

    2.5, 62.5

    Product Dimension Sheet

    49L7X15 Dimensions

    Top Plate Thickness (in, mm)

    0.5, 13

    Xmax (in, mm)

    1.25, 31.25

    Mounting Cutout (in, cm)

    13-3/4, 34.9

    Mounting Depth (in, cm)

    11-9/16, 29.3

    Recommended Vented Box Volume (Cu. Ft., L)

    5, 141.6

    Port Opening (in x in, cm x cm)

    4.25 X 16.5, 11 x 42

    Port Length (in, cm)

    34.75, 88

    Vented Enclosure Tuning Frequency (Hz)

    30
